CD 304 MK 3 :-)
Modified CD 304 MK2 with 8xOS staggered DAC SAA7220 Drop-in replacement SONY CXD114 Digital filter 8 Oversampled Staggerd , and dual TDA1541A Board. CXD 1244 Version and CXD 1144A Version 1M FFT , 10x...
Category: staggered
CXD 1144A vs CXD 1244
Is the CXD 1144 the big brother off the CXD -1244 or just the little brother Blockdiagram CXD 1144B , CXD1144A is used in the Sony ESD 227 with double TDA1541A i think that...
Staggered DAC
Building Staggered DAC upgrade basesed on CDX1144/1244 and TDA1541A DAC Information from Sony leaflet and service manual “DAS-r1” Overlap Staggered 8 Times DIA Conversion for distortion-free, low-noise signal reproduction .This system performs D/A conversion...
8 x Over Sampling TDA1541a – CXD 1244 ?
See also Staggered DAC Today I received the PCB for my new experiment Quickly poke some parts , and check SMD check footprints Idea based on grundig cd9009. SMD placed Some IC-sockets Check...
Grundig CD-9009 Fine-Arts
Een Grundig CD9009 alleen Defect op Display geeft, mooie speler twee TDA1541a S1 met DEM clock gesync aan de wordclock Loopwerk uitgebouwd. Servo print Clamper met Logo De speler draait weer na vervangen laser...
